product details
Type: QZ(G)L-155; PEWAL/155
Thermal Class(℃): Class F 155
Standard: GB/T 23312.3、GB/T 23312.4、MW24-A
Size Available: 0.15mm-6.0mm, AWG4-AWG34 , SWG4-SWG38
Contact Us product details
155°C F Aluminum Enameled Round Wire
Properties: Good heat resistance、Abrasion resistance、Good adhesion
Application:Various motors working at 130 C and 155 C/electric instruments,/coils for telecommunication equipments/coil for illuminating apparatus/ heat –resisting transformers/ degaussing coils .
Name | Polyester enameled round aluminum wire
| Modified Polyester Enameled Round Aluminum Wire |
Type | 1PEWAL,2PEWAL, 0PEWAL QZL-2/130,QZL-1/130,QZL-3/130 | 2PEW(W)/155, 1PEW(M)/155 QZ(G)NL-2/155,QZ(G)NL-1/155 |
Thermal class | 130 | 155 |
Standard | IEC60317-0 | |
Specification | ф 0.15mm-ф 6.00mm, AWG4-AWG34 , SWG4-SWG38 | |
Composition | Aluminum , polyester Resin | |
